GB-20008 MEASURING INSTRUMENTS CATALOGUE 2024 - 2026
Test Equipment and Seismometers Coordinate Measuring Machines Vision Measuring Systems Form Measurement Optical Measuring Sensor Systems Digital Scale and DRO Systems Small Tool Instruments and Data Management Competence and customer proximity on one spot Throughout Europe, the name Mitutoyo represents innovational power as well as outstanding quality in the field of sophisticated dimensional measuring solutions. In order to strengthen and synchronise the concerted pan-European activities, Mitutoyo established the European headquarters named Mitutoyo Europe GmbH in Neuss near Düsseldorf/Germany in January 2010. The headquarters oversees all the activities of Mitutoyo’s sales, service and production facilities throughout Europe and adjacent markets, e.g. of Turkey. It also plans and implements the medium and long term business strategies of such European operations. A Mitutoyo Europe GmbH key objective is to promote coordination amongst its European group companies in order to optimise its sales and technical support services in the best interests of customer satisfaction. More than 260 highly skilled members of staff work for the benefit of our customers in development, service, sales and administration. They are supported by the specialists of Mitutoyo CTL Germany GmbH in Oberndorf on the River Neckar, which focuses solely on developing ground-breakingly powerful and easy to use software for three-coordinate measurement technology. The peripheral fields of coordinate measuring machines, jigging and loading systems and thermal cabins are covered by KOMEG company based in Saarland. In addition to top-level measuring and testing equipment, the range of products also includes a wide selection of accessories and – as a further area of focus – sophisticated, high-performance software for coordinate measuring machines and vision measuring systems as well as surface roughness, hardness and form measurement. The Mitutoyo Information Center of Metrology (MIM) has been demonstrating the manufacturer’s commitment to advanced training in all fields of dimensional measurement technology since 1999. The MIM is open to anyone working in the fields of manufacturing, service, science and research. Mitutoyo Europe GmbH is, moreover, a corporate member of “Ausbildung Koordinatenmesstechnik e. V. (AUKOM)”. This association is dedicated to providing training schemes for coordinate measuring technology with the aim of ensuring a neutral, comprehensive and state of the art training concept. Germany has also been home to the Mitutoyo M³ Solutions Europe division since 2004. The abbreviation M³ stands for Mitutoyo Measurement Metrology and, as such, for the concept of special measuring solutions developed by Mitutoyo to meet the particular requirements of its customers across the whole breadth of length, form and surface measurement technology. The Mitutoyo Europe GmbH in Neuss offers sample configurations in the 400 m² M³ Solution Center Europe to demonstrate the numerous possibilities. The center also presents the smooth and seamlss integration of peripheral systems, such as jigs or feed and climate control systems from KOMEG alongside the measuring equipment. The range of products offered by Mitutoyo in Europe is divided into eight groups:
Styli Fixtures MANUAL Vision CNC Vision Automatic CMM Part Program Generation STRATO-Active Series MACH Ko-ga-me Series HR-620B Surftest SJ-410 MF Microscope Formtracer Avant FTA-C4000 Roundtracer Extreme RTX USB-ITPAK Version 3 Absolute Digimatic Indicator ID-C Linear Height LH-600F/FG Absolute Digimatic Indicator ID-F Highlights 3
Table of Contents Quality Management Software Digimatic Mini Processor Signal Cables Wireless Data Transmission etc. Height Gauge Height Gauge Accessories Height Gauge with Data Processing Unit 14 - 33 217 - 232 Data Management Height Gauges Micrometers Inside Measuring Instruments Auxiliary Equipment and Miscellaneous Gauge Blocks Calipers ABSOLUTE Digimatic Indicator Dial Indicator Accessories for Indicator Dial Test Indicator etc. Height Master Check Master Calibration Tools Indicators Calibration Instruments 233 - 296 318 - 332 34 - 128 129 - 164 297 - 317 333 - 356 165 - 201 Digimatic Micrometers and Mechanical Micrometers Micrometers Accessories Micrometer Heads Micrometer Head Accessories Depth Measuring Instruments 202 - 216 Depth Measuring Instruments Inside Micrometer Bore Gauges Inside Measuring Instruments Accessories Stands, Bench Tools, Vices, V-Blocks, Plates, Protectors, Levels, Squares, Rules, Spring Calipers Steel Gauge Block Sets Steel Individual Gauge Blocks CERA Gauge Block Sets CERA Individual Gauge Blocks etc. Absolute Digimatic Caliper Analog Caliper Special Puropose Caliper Caliper Accessories 4
Optical Measuring Magnifiers Measuring Microscopes Objectives Measuring Projectors Optical Measuring For better communication with our customers Form Measurement Sensor Systems and Laser Scan Micrometers Hardness Testing Indexes Scale Units and Linear Scales 357 - 377 378 - 399 Linear Gauges Counters and Display Units LITEMATIC Laser Scan Micrometer Surface Roughness Measuring Contour Measuring Form Measuring Instruments Mitutoyo's Domestic Network Mitutoyo's Overseas Network M3 Solution Centers Scale Units Linear Scale NC-Scales Hardness Testing Machines 400 - 452 453 - 509 510 - 536 590 - 593 INDEXES 594 - 601 CMM Software Mobile 3D Systems and Manual CMMs Small- and Medium Size CMMs Large Size CMMs etc. Coordinate Measuring Machines 537 - 570 Vision Measuring Machines Vison Measuring Machines Manual 2D VMM Quick Image Manual 2.5D VMM Quick Scope CNC VMM Quick Vison, MiSCAN 571 - 589 5
*1 Length and Temperature *2 Length and Hardness No mark is only length AIST: National Institute of Advanced Industrial Science and Technology NMIJ: National Metrology Institute of Japan JCSS: Japan Calibration Service System NITE: National Institute of Technology and Evaluation IAJapan: International Accreditation Japan A STAR : Agency for Science, Technology and Research SAC: Singapore Accreditation Council NML: National Measurement Laboratory TAF: Taiwan Accreditation Foundation NML-SIRIM: National Metrology Laboratory, Standards and Industrial Research Institute of Malaysia STANDARDS: MALAYSIA Department of Standards Malaysia NIST: National Institute of Standards and Technology A2LA: American Association for Laboratory Accreditation NRC-INMS: National Research Council of Canada-Institute for National Measurement Standards CLAS: Calibration Laboratory Assessment Service SCC: Standards Council of Canada CENAM: Centro Nacional de Metrologi´a EMA: Entidad Mexicana de Acreditacio´n, a.c. UKAS: United Kingdom Accreditation Service NMi: Nederlands Meetinstituut RvA: Raad voor Accreditatie PTB: Physikalisch-Technische Bundesanstalt DAkkS: Deutsche Akkreditierungsstelle GmbH METAS: The Swiss Federal Office of Metrology and Accreditation SAS: Swiss Accreditation Service IMGC: Istituto di Metrologia “ GUSTAVO COLONNETTI ” ACCREDIA:L’NTE ITALIANO DI ACCREDITAMENTO SP: Swedish National Testing and Research Institute SWEDAC: Swedish Board for Accreditation and Conformity Assessment INMETRO: Instituto Nacional de Metrologia Normalizacao e Qualidade Industrial RBC: Rede Brasileira de Calibracao INTI: Instituto Nacional de Tecnologia Industrial OAA: Organismo Argentino de Acreditaci NPL: National Physical Laboratory NABL: National Accreditation Board for Testing and Calibration Laboratories (ILAC): International Laboratory Accreditation Cooperation (APLAC): Asia-Pacific Laboratory Accreditation Cooperation (EA): European Accreditation Cooperation (MRA): Mutual Recognition Arrangement #: Accreditation No. NMIJ/ AIST IAJapan/NITE JCSS Mitutoyo Malaysia *2 No.SAMM152 Mitutoyo Taiwan *2 No.0336 Mitutoyo South Asia *2 No.C-0349 APLAC <MRA> SAC STANDARDS MALAYSIA TAF NABL ILAC <MRA> A STAR NML-SIRIM NML NPLI Japan Singapore, Indonesia, Thailand, Vietnam Malaysia India Taiwan Mitutoyo Miyazaki Plant No.0030 Mitutoyo Hiroshima Cal.Center *2 No.0109 Mitutoyo Kawasaki Cal.Center (Force) No.0086 Mitutoyo Techno Service Business Division No.0186 Mitutoyo Asia Pacific *2 No.LA-1996-0102-C Mitutoyo Thailand *2 No.LA-1996-0102-C-2 Mitutoyo Indonesia *2 No.LA-1996-0102-C-1 Mitutoyo Thailand (Cholburi Branch) *2 No.LA-1996-0102-C-2-1 Mitutoyo Utsunomiya Measurement Standards Cal.Center No.0031 Mitutoyo Vietnam No.LA-1996-0102-C-5 NPLI: National Physical Laboratory of India Mitutoyo Vietnam (Ho Chi Minh City Branch) No.LA-1996-0102-C-4 Natural metrology insitute Accreditation body Accredited calibration laboratory Offering Reliable Traceability Worldwide Calibration laboratories worldwide Mitutoyo has a system allowing comprehensive support for the calibration of precision measuring products in the global market. In order to provide calibration services on a global basis, Mitutoyo has calibration laboratories that have received ISO/IEC 17025 certification, which is an international standard, from the accredited organisations in each of the countries in which Mitutoyo operates and subsidiaries are located, both in Japan and overseas. 6
Mitutoyo South Asia *2 No.C-0349 Mitutoyo America (Elk Grove) *1 No.0750.01 Mitutoyo America Field Service *2 No.1643.01 Mitutoyo Canada *2 No.2003-05 Mitutoyo Mexicana (Length) No.D-45 Mitutoyo Mexicana (Hardness) No.DZA-10 Mitutoyo UK *2 No.0332 Mitutoyo Nederland No.K 086 Mitutoyo Messgeräte D-K-15096-01-00 Mitutoyo Schweiz SCS 074 Mitutoyo Italiana LAT N. 107 Mitutoyo Scandinavia No.1794 Mitutoyo Sul Americana *2 No.031 Mitutoyo Argentina No.LC 010 A2LA CLAS/ SCC EMA UKAS RvA DAkkS SAS ACCREDIA SWEDAC RBC OAA EA <MRA> NIST NPLI NRCINMS CENAM NPL VSL PTB METAS INRiM SP INMETRO INTI ndia Canada UK Germany Italy Brazil USA Mexico The Netherlands Switzerland Sweden Argentina 7
Mitutoyo Utsunomiya Measurement Standards Calibration Center (JCSS Accredited Cal. Lab. No.0031) 633nm Iodine Stabilized He-Ne Laser <Secondary Standard> National Metrology Institute of Japan / National Institute of Advanced Industrial Science and Technology (NMIJ/AIST) The atomic clock synchronized to UTC and the optical frequency comb <National (Primary) Standard> Mitutoyo Miyazaki Plant (JCSS Accredited Cal.Lab. No.0030) 633nm Stabilized He-Ne Laser <Laboratory Reference Standard> Mitutoyo Utsunomiya Measurement Standards Cal. Center (JCSS Accredited Cal. Lab. No.0031) Standard Gauge Block <Laboratory Reference Standard> Step Gage Gauge Block Ring Gage Dial Gage Tester Standard Scale Optical Flat/Parallel Optical Measuring Machine Vision Measuring Machine Form Measuring Machine Measuring Tool Precision Sensors Scale unit Thermometer Laser Length Measuring Machine Working Standard Measuring Instrument Mitutoyo Hiroshima Calibration Center (JCSS Accredited Cal.Lab. No.0109) Standard Gauge Block/ Micrometer Standard/Step Gage <Laboratory Reference Standard> Mitutoyo Utsunomiya Measurement Standards Calibration Center (JCSS Accredited Cal. Lab. No.0031) 633nm Stabilized He-Ne Laser JCSS Accredited Cal.Lab. Stabilized He-Ne Laser <Laboratory Reference Standard> NMIJ/AIST Temperature fixed points <National (Primary)Standard> JEMIC Temperature fixed point <National (Sub-Primary) Standard> JCSS Accredited Cal.Lab. Temperature fixed point/ Platinum resistance thermometer <Secondary Standard> Mitutoyo Utsunomiya Measurement Standards Cal. Center (JCSS Accredited Cal. Lab. No.0031) Temperature fixed point (Triple point of water)/ Platinum resistance thermometer <Laboratory Reference Standard> Traceability of length Traceability of temperature Mitutoyo Techno Service Business Division (JCSS Accredited Cal.Lab. No.0186) Standard Gauge Block/Step Gage Coordinate Measuring Machine Mitutoyo Utsunomiya Measurement Standards Cal. Center (JCSS Accredited Cal. Lab. No.0031) Standard Gauge Block/ Micrometer Standard/Step Gage Note: This chart is a simplified representation of Mitutoyo's overall traceability system. Detailed traceability charts are published for each product. Offering High-level Calibration Services Worldwide Based on highest measurement capabilities of the same level as national standards Traceability system Mitutoyo has a traceability system made possible through an in-house calibration organisation certified by the ISO/IEC 17025 international standard, with length standards directly related to national standards (atomic clock synchronised to UTC and the optical frequency comb) at the highest level. National standards are mutually recognised by CIPM, and the certified calibration organisation is mutually recognised by ILAC, so that the establishment and maintenance of traceability for Mitutoyo products is achieved both in Japan and overseas. Certificate of JCSS accredited laboratory (Mitutoyo Utsunomiya Measurement Standards Calibration Center) 8
National Metrology Institute of Japan / National Institute of Advanced Industrial Science and Technology (NMIJ/AIST) Mitutoyo Hiroshima Calibration Center (JCSS Accredited Cal.Lab.No.0109) Rockwell Hardness Reference Blocks*1 <Secondary Standard> Mitutoyo Hiroshima Calibration Center (JCSS Accredited Cal.Lab.No.0109) Hardness Reference Blocks*1 Mitutoyo Kawasaki Calibration Center (JCSS Accredited Cal.Lab.No.0086) Force-proving Instruments <Secondary Standard> Mitutoyo Utsunomiya Measurement Standards Cal. Center (JCSS Accredited Cal. Lab. No.0031) 633nm Iodine Stabilized He-Ne Laser <Secondary Standard> Mitutoyo Utsunomiya Measurement Standards Cal. Center (JCSS Accredited Cal. Lab. No.0031) 633nm Stabilized He-Ne Laser Mitutoyo Miyazaki Plant (JCSS Accredited Cal.Lab. No.0030) 633nm Stabilized He-Ne Laser <Laboratory Reference Standard> Vibration Testing Machine / Vibrometer *1 The scope of JCSS accreditation is from 20HRC up to 65HRC in Rockwell Hardness Testing Machines and Hardness Reference Blocks. Note: This chart is a simplified representation of Mitutoyo's overall traceability system. Detailed traceability charts are published for each product. Reference Weights NIPPON KAIJI KYOKAI Japan Bearing Inspection Institute Force Measuring Machine Reference Indenters Indenters Balance Vibration Reference Device Electric standards National Institute of Information and Communications Technology Japan Electric Meters Inspection Corporation Japan Quality Assurance Organization ORIX Rentec Corporation Gauge Block / Step Gage Standard Scale Test Equipment Traceability of Test Equipment Mitutoyo Hiroshima Calibration Center (JCSS Accredited Cal.Lab.No.0109) Standard Hardness Reference Machine*1 Testing Weights Vibration Testing Machine Vibro Meter Seismological Instruments Balancing Machine Hardness Testing Machine Piezoelectric /Servo Acceleration Pickup CE Marking Directives CE stands for “Conformité Européenne”, a challenging and important task for Mitutoyo in Europe. For Mitutoyo as a manufacturer of measuring electronics and measuring machines this means no sale without CE marking, no CE marking without completed conformity assessment procedure. CE Marking Directives 9
Meaning of Symbols ABSOLUTE Linear Encoder Mitutoyo's technology has realised the absolute position method (absolute method). With this method, you do not have to reset the system to zero after turning it off and then turning it on. The position information recorded on the scale is read every time. The following three types of absolute encoders are available: electrostatic capacitance model, electromagnetic induction model and model combining the electrostatic capacitance and optical methods. These encoders are widely used in a variety of measuring instruments as the length measuring system that can generate highly reliable measurement data. Advantages: 1. No count error occurs even if you move the slider or spindle extremely rapidly. 2. You do not have to reset the system to zero when turning on the system after turning it off*1. 3. As this type of encoder can drive with less power than the incremental encoder, the battery life is prolonged to about 3.5 years (continuous operation of 18,000 hours)*2 under normal use. *1: Unless the battery is removed *2: In the case of the ABSOLUTE AOS Digimatic caliper (electromagnetic encoder model) Measuring Instruments Shipped with Inspection Certificate Mitutoyo guarantees product quality as a leading precision measuring instrument manufacturer and ships measuring instruments with an inspection certificate that includes inspection data so that customers can use them with confidence. Mitutoyo also calibrates the purchased measuring instrument and issues, for a fee, a calibration certificate that proves traceability to the relevant standard. * For the meaning of the inspection marks shown at left, refer to the detailed description of each product IP Codes These are codes that indicate the degree of protection provided (by an enclosure) for the electrical function of a product against the ingress of foreign bodies, dust and water as defined in IEC standards (IEC 60529: 2001) and JIS C 0920: 2003. [IEC: International Electrotechnical Commission] *: For details of the test conditions used in evaluating each degree of protection, please refer to the original standard. First characteristic numeral Degrees of protection against solid foreign objects Brief description Definition 0 Unprotected — 1 Protected against solid foreign objects of Sø50 mm and greater A Sø50 mm object probe shall not fully penetrate enclosure* 2 Protected against solid foreign objects of Sø12.5 mm and greater A Sø12.5 mm object probe shall not fully penetrate enclosure* 3 Protected against solid foreign objects of Sø2.5 mm and greater A Sø2.5 mm object probe shall not fully penetrate enclosure* 4 Protected against solid foreign objects of Sø1.0 mm and greater A Sø1.0 mm object probe shall not fully penetrate enclosure* 5 Protected against dust Ingress of dust is not totally prevented, but dust that does penetrate must not interfere with satisfactory operation of the apparatus or impair safety. 6 Dust-proof No ingress of dust allowed. 7 — 8 — Second characteristic numeral Degrees of protection against water Brief description Definition 0 Unprotected — 1 Protected against vertical water drops Vertically falling water drops shall have no harmful effects. 2 Protected against vertical water drops within a tilt angle of 15 degrees Vertically falling water drops shall have no harmful effects when the enclosure is tilted at any angle up to 15° on either side of the vertical. 3 Protected against spraying water Water sprayed at an angle up to 60° either side of the vertical shall have no harmful effects. 4 Protected against splashing water Water splashed against the enclosure from any direction shall have no harmful effects. 5 Protected against water jets Water projected in jets against the enclosure from any direction shall have no harmful effects. 6 Protected against powerful water jets Water projected in powerful jets against the enclosure from any direction shall have no harmful effects. 7 Protection against water penetration Ingress of water in quantities causing harmful effects shall not be possible when the enclosure is temporarily immersed in water under standardised conditions of pressure and time. 8 Protected against the effects of continuous immersion in water Ingress of water in quantities causing harmful effects shall not be possible when the enclosure is continuously immersed in water under conditions which shall be agreed between manufacturer and user but which are more severe than for IPX7. Main Unit Startup System Installation of Main Unit Startup System As a part of the enhancement of our export control system, the CNC measuring machines (all the CNC Coordinate Measuring Machines, Vision Measuring Systems, and Form Measuring Machines) are equipped with a Main Unit Startup System (relocation detecting system). This system is designed to take a machine out of operation upon detecting the mechanical shock that accompanies relocation. If you intend to relocate a measuring machine fitted with this system, please contact us beforehand so that our service engineers can assist you. On the other hand, the system may be triggered in the event of a natural event such as a powerful earthquake. In this case, our service engineers will deal with the situation at the earliest opportunity. 10
Metric/Inch Mitutoyo offers this quality product also in an switchable Metric/Inch version. Please refer to your local Mitutoyo website for detailed information. Inch/Metric Mitutoyo offers this quality product also in an switchable Inch/Metric version. Please refer to your local Mitutoyo website for detailed information. Inch Mitutoyo offers this quality product also in an Inch version. Please refer to your local Mitutoyo website for detailed information. Independent Confirmation of Compliance IP65, IP66 and IP67 protection level ratings for applicable Mitutoyo products have been independently confirmed by the German certification organisation, TÜV Rheinland. 11
Example of Measurement Data Management System Design A system for recording and analysing measurement results from various Mitutoyo measuring instruments for quality assurance purposes. Recording measurement results Measurement data can be printed easily. Data can be output to a PC for statistics calculations. DP-1VR U-WAVE Multiplexer MUX-10F Input Tool Series Implementation Step 2 Software dedicated to inspection and quality control USB-ITPAK MeasurLink Digimatic gages U-WAVE-R U-WAVE-T GO/NG judgment, process capability, control charts are displayed in real time. U-WAVE-R USB U-WAVE-T 1ch USB RS-232C RS-232C 4ch USB Input Tool Series Implementation Step 1 USB 1ch Connectable to a RS-232C interface PC with 4 channels and a sequencer USB-ITN-B USB-ITN-C 4 SUB-FSW cables + 4 foot switches Commercial USB hub Measurement data from calipers and micrometers are imported into an Excel(R) spreadsheet. No more handwriting Direct data input to a PC Wireless Inspection certificate creation Statistical process control A B C D E F 1 Setting 1 2 3 4 5 2 Dimension X 10.025 10.033 9.964 10.031 10.046 3 Dimension Y 9.982 10.017 10.008 9.996 10.027 4 Dimension H 29.97 30.02 30.07 29.96 30.04 5 External Appearance OK OK NG and DMX Interfaces All products to be sold to commercial customers. Product illustrations are without obligation. Product descriptions, 12 All products to be sold to commercial customers. Product illustrations are without obligation. Product descriptions, in particular any and all technical specifications, are only binding when explicitly agreed upon.
n Implementation Step 3 Creating a quality control network covering a wide area within the factory 2 me. MeasurLink om ters Excel(R) Database server Quality control Inspection room QM-Data200 Optical measuring device Terminal of the quality controller Storage of database Generation of inspection certificates Offi ce CMM MCOSMOS QVPAK Vision measuring machine Digimatic gages U-WAVE-R U-WAVE-T LAN inside factory Database server centralises inspection results The quality control section monitors results from the inspection room and worksite, handles statistical analysis of stored data and issues forms. Production line 46 27 04 Unify management of the quality test using the network in the factory All products to be sold to commercial customers. Product illustrations are without obligation. Product descriptions, in particular any and all technical specifications, are only binding when explicitly agreed upon. 13
Data Management Quality Management Software Page 15 Digimatic Mini Processors Page 20 Signal Cables Page 21 Wireless Communication System U-WAVE Page 24 Digimatic Interface Page 28 Timerbox, Digimatic Switch Box Page 33 All products to be sold to commercial customers. Product illustrations are without obligation. Product descriptions, 14 All products to be sold to commercial customers. Product illustrations are without obligation. Product descriptions, in particular any and all technical specifications, are only binding when explicitly agreed upon.
MeasurLink 10 MeasurLink brochure available on request An Integrated Solution for Quality Data Management Most of Mitutoyo's electronic instruments can output data via optional connecting cables or wireless transmitters & receivers in the form of the Digimatic code. The Digimatic code can also be converted in RS-232C format by any of several available gage multiplexers. In this way, digital data can be sent to PCs for data acquisition and advanced statistical analysis. As a client/server application, MeasurLink gives you the performance you need through distributed processing. Combined with a multi-user relational database, MeasurLink delivers a safe and organized data warehousing system making quality data available for viewing and analysis by any member of the production, engineering and managerial staff throughout your company. Inspection in the factory produces data for analysis, corrective action, and various reporting needs. As the backbone of your quality efforts, MeasurLink is guaranteed to reduce your production costs and increase your buttom line. MeasurLink is capable of linking and managing multiple "islands" of inspection into a common database of part information, statistical data, gage information, process, etc. Information is shared across an entire manufacturing facility. Group Licensing MeasurLink is available in several modules offering you a wide range of solutions, from data acquisition to manager views and gage management. Details about all modules can be found on the next pages. However, you can create your own package and combine modules by choosing one of the following license bundles: CMM Data Base Others production processes Customers Suppliers Operator Operator Operator Operator Channels Channels Interface Interface Quality Management Production Management 1 2 3 1 2 3 No. Description 64AAB843R MeasurLink 10 Site License - 30 Licenses* 64AAB844R MeasurLink 10 Workgroup License - 15 Licenses* 64AAB846R MeasurLink 10 Workgroup License - 10 Licenses* 64AAB847R MeasurLink 10 Workgroup License - 5 Licenses* 64AAB845R MeasurLink 10 Additional Site License - 1 License after 30 Licenses* 64AAB848R MeasurLink 10 Academic License - 20 Licenses* 64AAB843R-U MeasurLink 10 Site License Upgrade - 30 Licenses* 64AAB844R-U MeasurLink 10 Workgroup License Upgrade - 15 Licenses* 64AAB846R-U MeasurLink 10 Workgroup License Upgrade - 10 Licenses* 64AAB847R-U MeasurLink 10 Workgroup License Upgrade - 5 Licenses* 64AAB845R-U MeasurLink 10 Additional Site License Upgrade - 1 License after 30 Licenses* 64AAB848R-U MeasurLink 10 Academic License Upgrade - 20 Licenses* *Real-Time Professional 3D is not included All products to be sold to commercial customers. Product illustrations are without obligation. Product descriptions, in particular any and all technical specifications, are only binding when explicitly agreed upon. 15
MeasurLink 10 MeasurLink Real-Time Standard Edition MeasurLink 10 Real-Time Standard Edition is designed for customers that do not need to connect to major instruments such as CMMs, Vision and Form, etc. systems via DDE or ASCII file import. It has basic views to allow the user to create Parts, Characteristics with nominal and tolerance, Traceability lists, etc. The data collection interface provides real-time graphics for Run charts, Control charts, Histograms, Statistics, etc. Standard views include the Datasheet (observations and charts), the Classic View (chart windows), and the 2D view (pictures with callouts that include charts and statistical data). This application does not support data filters. Full reporting functionality with templates is provided. Supported data sources include keyboard, RS232C, HID, MTConnect, OPC UA and MQTT devices. No. Description 64AAB836R MeasurLink 10 Real-Time Standard 64AAB836R-U MeasurLink 10 Real-Time Standard Upgrade MeasurLink Real-Time Professional Edition MeasurLink 10 Real-Time Professional Edition is designed for customers that do need to connect to major instruments such as CMMs, Vision and Form, etc. systems via DDE or ASCII file import. It has basic views to allow the user to create Parts, Characteristics with nominal and tolerance, Traceability lists, etc. The data collection interface provides real-time graphics for Run charts, Control charts, Histograms, Statistics, etc. Standard views include the Datasheet (observations and charts), the Classic View (chart windows), and the 2D view (pictures with callouts that include charts and statistical data). This application does support data filters. Full reporting functionality with templates is provided. Supported data sources include keyboard, RS232C and HID devices, MTConnect, OPC UA, MQTT, DDE, ASCII and QIF (xml-based) file imports. No. Description 64AAB837R MeasurLink 10 Real-Time Professional 64AAB837R-U MeasurLink 10 Real-Time Professional Upgrade Optional accessories No. Description 937179T Footswitch for SPC 63AAA424 USB-Space Footswitch Interface MeasurLink Real-Time Professional 3D Edition MeasurLink 10 Real-Time Professional 3D Edition is designed for customers that wish to collect data using the Hoops 3D graphics view. It has basic views to allow the user to create Parts, Characteristics with nominal and tolerance, Traceability lists, etc. The data collection interface provides real-time graphics for Run charts, Control charts, Histograms, Statistics, etc. Standard views include the Datasheet (observations and charts), the Classic View (chart windows), and the 2D view (pictures with callouts that include charts and statistical data). This application does support data filters. Full reporting functionality with templates is provided. Supported data sources include keyboard, RS232C and HID devices, MTConnect, OPC UA, MQTT, DDE, ASCII and QIF (xml-based) file imports. No. Description 64AAB838R MeasurLink 10 Real-Time Professional 3D 64AAB838R-U MeasurLink 10 Real-Time Professional 3D Upgrade Optional accessories No. Description 63AAA424 USB-Space Footswitch Interface 937179T Footswitch for SPC All products to be sold to commercial customers. Product illustrations are without obligation. Product descriptions, 16 All products to be sold to commercial customers. Product illustrations are without obligation. Product descriptions, in particular any and all technical specifications, are only binding when explicitly agreed upon.
MeasurLink 10 MeasurLink Process Analyse Professional Edition MeasurLink 10 Process Analyzer Professional Edition is designed for Quality Engineers. Offline viewing of Real-Time data in a networked environment, all views supported by Real-Time Standard edition are supported. Full reporting is provided. Data is organized by Station, Part or Routine. Merging, Filtering, What-if scenarios and advanced statistical treatments are supported. No. Description 64AAB839R MeasurLink 10 Process Analyzer Professional 64AAB839R-U MeasurLink 10 Process Analyzer Professional Upgrade MeasurLink Process Manager Standard Edition MeasurLink 10 Process Manager is a dashboard view of the current shop floor activity from a single computer. It displays those characteristics that are most in need of attention or adjustment. The view automatically updates to show a current state of measurement activity. No. Description 64AAB840R MeasurLink 10 Process Manager 64AAB840R-U MeasurLink 10 Process Manager Upgrade MeasurLink Gage R&R MeasurLink 10 Gage R&R is a collection of techniques whose purpose is to measure the capability of a measurement system for a measurement task. No. Description 64AAB841R MeasurLink 10 Gage R&R 64AAB841R-U MeasurLink 10 Gage R&R Upgrade MeasurLink Gage Management MeasurLink 10 Gage Management is designed for Gage inventory management with Calibration procedures and recall methods. No. Description 64AAB842R MeasurLink 10 Gage Management 64AAB842R-U MeasurLink 10 Gage Management Upgrade MeasurLink Report Scheduler V10 MeasurLink 10 Report Scheduler is a tool that can be used to schedule MeasurLink reports for print, export or email as Adobe PDF files. No. Description 64AAB853R MeasurLink 10 Report Scheduler 64AAB853R-U MeasurLink 10 Report Scheduler Upgrade All products to be sold to commercial customers. Product illustrations are without obligation. Product descriptions, in particular any and all technical specifications, are only binding when explicitly agreed upon. 17
USB-ITPAK Series 06 USB-ITPAK Version 3 is software for collecting data from measuring instruments with Digimatic, Digimatic 2 and Digimatic S1 output to Excel by using USB Input Tool Interface, USB Input Tool Direct cables, U-WAVE wireless system and DP-1VA pinter/logger • Supports bidirectional serial communication provided by e.g. ID-F/ ID-C Indicator (2022 model), Height Gauge LH-600F/FG and QuantuMike Micrometer (2024 model) • Various settings are available like zero set, preset, unit, counting direction, tolerance setting, calibration date setting a.s.o. • Measurement status information can be read like serial number, code number, calibration date, user control number a.s.o. • USB-ITPAK Version 3 simple version is available online free of charge • In order to use the full functionality of the software, no. 06AGR543 must be ordered • Compatible OS Microsoft® Windows® 10 (64 bit) and 11 • For Microsoft® Excel® version 2010, 2013, 2016 and Microsoft 365 No. Remarks 06AGR543 Version 3.0 can be used for Wireless Communication (U-WAVE and U-WAVE Bluetooth), USB Input Tool Direct Cable, USB-Input Tool No. 264-016-10 and 264-020 and DP-1 VA printer/logger. Supports bidirectional serial communication provided by e.g. ID-F/ ID-C Indicator (2022 model), LH-600 F/FG and QuantuMike Micrometer (2024 model). Specifications OS compatibility Windows® 10 (64bit), 11 Applicable MS Excel Version Excel 2010/2013/2016/2021, MS 365 Language for display English, German, French, Italian, Spanish, Turkish, Czech, Polish, Hungarian, Swedish, Russian, Japanese, Korean, Simplified Chinese, Traditional Chinese, Dutch, Portuguese Functions • Create Microsoft® Excel® input procedures (workbook, worksheet, cell range a.s.o.) • Bidirectional communication (Digimatic S1) compatible (Vers. 3 only) • Information reading of measuring tools e.g. serial number, code number etc. (Vers. 3 only) • Settings and operations of measuring tools e.g. preset, power ON/OFF, etc. (Vers. 3 only) • Enter measured data in the quick entry mode (Vers. 3 only) • Enter measured data in a specified sequence (sequencial mode) • Enter measured data all at once (batch mode) • Enter measured data individually (individual mode) • Automatically enter measurement data periodically • Enter a string with your foot • Enter measurement data with foot switch, keyboard/mouse, data switch • Enter data into an arbitrary application • Enter log data from DP-1VA LOGGER Delivered License key (software can be downloaded from our website) All products to be sold to commercial customers. Product illustrations are without obligation. Product descriptions, 18 All products to be sold to commercial customers. Product illustrations are without obligation. Product descriptions, in particular any and all technical specifications, are only binding when explicitly agreed upon.
USB-ITPAK Optional accessories No. Description 06AFM380A USB Input Tool Direct (Digimatic USB), Digi/Digi2, With Data Button IP Caliper Type 06AFM380B USB Input Tool Direct (Digimatic USB), Digi/Digi2, With Data Button IP Micrometer Type 06AFM380C USB Input Tool Direct (Digimatic USB), Digi/Digi2, Straight, with Data Button 06AFM380D USB Input Tool Direct (Digimatic USB), Digi/Digi2, Flat 10-Pin Type 06AFM380E USB Input Tool Direct (Digimatic USB), Digi/Digi2, Round 6-Pin Type 06AFM380F USB Input Tool Direct (Digimatic USB), Digi/Digi2, Flat Straight Type 06AFM380G USB Input Tool Direct (Digimatic USB), Digi/Digi2, Flat Straigt IP Type 06AGQ001F USB Input Tool Direct, Indicator Type, 2m Cable, Digimatic/Digimatic 2/Digimatic S1 Interface 06ADV384 USB Input Tool Direct, Footswitch Adapter 264-020 USB Input Tool Interface Box, Digimatic/ Digimatic 2/Digimatic S1 Interface 264-623 U-WAVE fit, Buzzer Type (not IP rated), Wireless Transmitter for Micrometer 264-622 U-WAVE fit, IP67 Type, Wireless Transmitter for Micrometer 264-621 U-WAVE fit, Buzzer Type (not IP rated), Wireless Transmitter for Caliper 264-620 U-WAVE fit, IP67 Type, Wireless Transmitter for Caliper 02AZD730G U-WAVE-T, IP67 Type, Wireless Transmitter 02AZD880G U-WAVE-T, Buzzer Type, Wireless Transmitter 264-627 U-WAVE fit Bluetooth, Buzzer Type (not IP rated), Wireless Transmitter for Micrometer 264-626 U-WAVE fit Bluetooth, IP67 Type, Wireless Transmitter for Micrometer 264-625 U-WAVE fit Bluetooth, Buzzer Type (not IP rated), Wireless Transmitter for Caliper 264-624 U-WAVE fit Bluetooth, IP67 Type, Wireless Transmitter for Caliper 264-505D Statistic Processing Printer DP-1VA, Data Printer and Logger CEE Type Microsoft® Excel® Worksheet waiting for data 3 H Y X 1 2 A B C D E F 1 Setting 1 2 3 4 5 2 Dimension X 10.025 10.033 9.964 10.031 10.046 3 Dimension Y 9.982 10.017 10.008 9.996 10.027 4 Dimension H 29.97 30.02 30.07 29.96 30.04 5 External Appearance OK OK NG Data cancellation OK NG Data request Excel Table 4 5 6 7 8 9 Sequential Measurement 1: Micrometer for diameters X and Y 2: Caliper for height measurement H 3: Inspection by attributes OK/NG with foot switch e.g.scratches in the surface 4: standard USB-HUB 5: Measurement direction 6: Workpiece No. 7: Measuring result X/Y 8: Measuring result H 9: OK/NG judgement (e.g. scratches) 1 2 3 4 5 Height A B C D A B C D E 1 Height A Height B Height C Height D 2 1 5.02 8.03 9.96 6.03 3 2 4.98 8.02 10.01 5.99 4 3 4.97 8.04 10.07 5.96 5 4 6 5 Data cancellation Data request Simultaneous Measurement 1: Measurement direction 2: First measurement: press foot switch once = 4 complete data batches 3: second measurement: press foot switch once = 4 complete data batches 4: third measurement: press foot switch once = 4 complete data batches 5: is waiting for the next batch measurement All products to be sold to commercial customers. Product illustrations are without obligation. Product descriptions, in particular any and all technical specifications, are only binding when explicitly agreed upon. 19
Digimatic Mini Processor DP-1VA LOGGER Series 264 This DP-1VA printer allows you to print measuring data, statistical evaluations a.s.o. • Digimatic 2 support. 8 digits output for data printing and analysis even from high resolution or long stroke instruments. • Statistical evaluations, and data printout from calipers, micrometers and other measuring devices equipped with a Digimatic port. • Excellent printing speed, prints upon one-touch start and at low noise level. The thermosensitive paper has outstanding durability and chemical resistance for long-term storage. • Timer function for timed measurement data loading • Easy data transfer from printer to PC. USB (VCP/HID) output for PC (USB IT-PAK Vers. 2,1 or later, MeasurLink, Excel a.s.o.) • Data Logger Function. Saves up to 1000 data records with time and date. Data can be saved even after the power is turned off. 264-505D No. Delivered Mass [g] 264-505D With AC adapter, printer paper (1 roll), strap 390 Mode 0 Mode 3 Modes 1,2 GO/±NG judgment N : Number of data MAX : Maximum value MIN : Minimum value R : Range X : Average value n : Standard deviation of the sample (N) n-1 : Sample standard deviation (N-1) -NG : Number of data smaller than lower limit value +NG : Number of data larger than upper limit value P : Fraction defective Cp : Process capability index Cpk : Process capability index (process target centered) N : Number of data MAX : Maximum value MIN : Minimum value n : Number of subgroup (Max.10) X : Average value of subgroup R : Range of subgroup X : Mean value X-UCL : Upper control limit R : Mean (R control) R-UCL : Upper control limit (R control) R-LCL : Lower control limit (R control) Specifications Data input Digimatic, Digimatic 2, RS-232C Input (KA-Counter only) Printer type Thermal line printer Printer speed 6,5 mm/s (using AC adapter) Printer line number 7000 lines/roll (with large font) 10000 lines/roll (with normal font) Printer paper Width: 58 mm, length: 48 m Processing capacity Mode 0: 100000 data entries Mode 1/2: 9999 data entries Mode 3: sample size 10x subgroup 9999 = total number of data entries 99990 Logging of the measurement data (to store) Max. 1000 points Data output USB, RS-232C at TTL level, tolerance judgment result (-NG, GO, +NG) Power supply AC adapter 6V, battery: LR6 x 4 (alkaline) or AA x 4 Ni-MH (rechargeable, battery is not charged in the device) Battery life Appr. 10000 lines (with 1600 mA Ni-MH and print 1 time/5 s) Timer function 0,25 s; 1 s; 5 s; 30 s; 1 min; 30 min; 60 min (0,25 s only statistical function) Standard accessories No. Description 06AGZ369D AC-Adapter, DC 6V 2A, CEE version Germany (Europe) 09EAA069D Thermal Printer Paper DP1-VR/-VA, 1 Roll Optional accessories No. Description 06AGR543 USB-ITPAK Vers. 3.0, USB Dongle + Manual (Software available Online) 09EAA084 RS-232C Cable, DP-1VR/VA to PC, 1m, 9 Pin Connector 06AFZ050 USB Cable 1m, DP-1VA to PC etc., USB Type A to Micro USB Type B Plug 965516 GO/±NG judgement cable, for external device, 2m 09EAA094 RS-232C Cable, DP1-VR/-VA to KA-Counter, 1m, 25 Pin Connector 937179T Footswitch for SPC 09EAA082-5 Thermal Printer Paper DP1-VR/-VA, 5 Rolls 011037 Battery, LR6, 1,5V, 4 pcs. 09EAA084 and 965516 can not be used simultaneously. All products to be sold to commercial customers. Product illustrations are without obligation. Product descriptions, 20 All products to be sold to commercial customers. Product illustrations are without obligation. Product descriptions, in particular any and all technical specifications, are only binding when explicitly agreed upon.
USB Input Tool Direct (Digimatic-USB Cable) Specifications Cable length 2 m Output USB: HID (keyboard format) or VCP (virtual COMPort) Max connectable devices 20 cables Optional accessories No. Description 06AGR543 USB-ITPAK Vers. 3.0, USB Dongle + Manual (Software available Online) 06ADV384 USB Input Tool Direct, Footswitch Adapter 937179T Footswitch for SPC 937179T and 06ADV384 Common USB Hub 06AFM380A 06AFM380B 06AFM380C 06AFM380D 06AFM380E 06AFM380F 06AFM380G For more information about cable connectors see the end of this chapter. 06AGQ001F Scan QR Code with your mobile device and watch our product videos on YouTube Digimatic-USB Cable This input tool allows you to directly connect Digimatic measuring devices to the USB interface of a PC, without needing additional software. Measurement data is then converted into keyboard codes, enabling interaction with any software such as Microsoft® Excel® working with keyboard entries (HID). When using the VCP (virtual COM-Port) driver which is part of USB-ITPAK Vers. 3 (easy input mode version), a fixed COM-Port assignment in Microsoft® Windows® is possible. A VCP can be used e.g. for professional SPC software like Mitutoyo MeasurLink. The driver is available online, free of charge. The following additional features are made available by adding the optional USB-ITPAK Vers. 3 (full version) to your workstation: • Creation of worksheets and multi-channel input for measurement values to Microsoft® Excel® • Automatic calling of said Excel® sheet for data input • Cursor movement after data input can be set to enable automatic input • Configuration of measuring methods, such as sequential measurement, batch measurement, individual measurement, and more • Timed data requests 06AFM380C No. Model OS compatibility Remarks 06AFM380A A Windows® 2000, XP, Vista, 7, 8/8.1, 10, 11 USB Input Tool Direct Cable Straight With Data Switch (2m), e.g. for IP67 Caliper 06AFM380B B Windows® 2000, XP, Vista, 7, 8/8.1, 10, 11 USB Input Tool Direct Cable Back Side With Data Switch (2m); e.g. for IP65 Micrometer 06AFM380C C Windows® 2000, XP, Vista, 7, 8/8.1, 10, 11 USB Input Tool Direct Cable Straight With Data Switch (2m); e.g. for Standard Absolute Caliper 06AFM380D D Windows® 2000, XP, Vista, 7, 8/8.1, 10, 11 USB Input Tool Direct Cable Plain (2m) e.g. for ID-H Indicator 06AFM380E E Windows® 2000, XP, Vista, 7, 8/8.1, 10, 11 USB Input Tool Direct Cable Round (2m) e.g. for Caliper Gauge Series 209 06AFM380F F Windows® 2000, XP, Vista, 7, 8/8.1, 10, 11 USB Input Tool Direct Cable Straight (2m) e.g. for ID-S Indicator 06AFM380G G Windows® 2000, XP, Vista, 7, 8/8.1, 10, 11 USB Input Tool Direct Cable ID-N/ID-B (2m) 06AGQ001F SF Windows® 10 (64 bit) / Windows® 11 USB Input Tool Direct Cable for measuring tools with Digimatic S1 bidirectional interface All products to be sold to commercial customers. Product illustrations are without obligation. Product descriptions, in particular any and all technical specifications, are only binding when explicitly agreed upon. 21
Digimatic Data Cables Digimatic Cables This is an overview of available data cables, and how you can connect measuring devices with data output e.g.to a PC. The cables listed are used to connect the measuring devices directly via USB (USB Input Tool Direct Cables), indirectly via standard Digimatic cables and interface box (e.g. DMX box or USB Input Tool Box), or the U-WAVE-T wireless transmitters (box version) to a PC. Please find the appropriate cable for your particular Digimatic measuring instrument in the “Optional Accessories” section of its product entry. 28.4 10.5 8 8.3 13 1 1.95 7 8 8 1 1 (1) 06AGQ001F (2) 06AGL011 (1m) 06AGL021 (2m) (3) 02AZG011 (Standard) 02AZG021 (FSW) (1) USB Input Tool Direct Cable 2 m (2) Standard Digimatic Cable 1 m or 2 m (3) U-WAVE Connection Cable (Standard) (3) U-WAVE Connection Cable with Footswitch Connector (FSW) All products to be sold to commercial customers. Product illustrations are without obligation. Product descriptions, 22 All products to be sold to commercial customers. Product illustrations are without obligation. Product descriptions, in particular any and all technical specifications, are only binding when explicitly agreed upon.
Digimatic Extension Cables Optional accessories No. Description 936937 Digimatic Cable, Flat 10-Pin Type, 1 m 965014 Digimatic Cable, Flat 10-Pin Type, 2 m Extension Cables for Digimatic Cables These extension cables allow you to extend Digimatic data cables up to 14 m, extending the working distance between a measuring instrument and an external device such as a PC or DP-1VA Logger/Printer. 63AAA036 No. 63AAA034 5 m No. 63AAA035 8 m No. 63AAA036 10 m DIGIMATIC Signal cable to the measuring instruments 1 m or 2 m DIGIMATIC Signal cable No. 936937 1 m No. 965014 2 m DIGIMATIC measurement devices with data output DIGIMATIC transmitters or Digimatic Miniprocessor Digimatic Extension Cable No. Length [m] 63AAA034 5 63AAA035 8 63AAA036 10 All products to be sold to commercial customers. Product illustrations are without obligation. Product descriptions, in particular any and all technical specifications, are only binding when explicitly agreed upon. 23
U-WAVE U-WAVE and U-WAVE fit - Wireless Data transmission system • Approx. 20 m (within visible range). • Communication frequency: 2,4GHZ wireless system for reliable and secure data transmission. • Easy data export to Easy data export to Microsoft® Excel® or other professional SPC software applications like Mitutoyo MeasurLink. • Transmitter confirms data transfer by a buzzer sound or a red/green LED signal. • Low power consumption: 400000 data transmissions with one battery. • U-WAVE Event will also support a data request from a PC. This is ideal if the system is installed at an inaccessible side. PC with U-WAVE-R (Receiver) For Caliper U-WAVE-TC (U-WAVE fit transmitter) with Connection Unit For Micrometer U-WAVE-TM (U-WAVE fit transmitter) with Connection Unit For miscellaneous measuring instruments U-WAVE-T (Transmitter) with Connection Cable Specifications Wireless communication protocol Proprietary (2,4 GHz by original specification based on IEEE 802.15.4) Modulation method DS-SS (Direct Sequence Spread Spectrum) Communication distance Approx. 20 m (within visible range) Communication speed kbps 250 Communication frequency 2,4 GHz band (2,405-2,475 GHz, 15 channels (5 MHz interval) Communication with measuring tool Digimatic (6 digits), Digimatic 2 (8 digits) automatic identification OS compatibility Windows® 2000 Professional (≥SP4), Windows® XP Professional (≥SP2), Windows® XP Home Edition (≥SP2), Windows Vista®, Windows® 7 (32bit, 64bit), Windows® 8, 8. 1, 10 (32bit, 64bit), 11 Standard accessories No. Description 05SAA217D Lithium battery CR-2032, 1 pcs. Optional accessories No. Description 06AGR543 USB-ITPAK Vers. 3.0, USB Dongle + Manual (Software available Online) 02AZF300 Connection Unit, U-WAVE fit, U-WAVE fit, U-WAVE fit Bluetooth 02AZF310 Connection Unit, U-WAVE fit, U-WAVE fit, U-WAVE fit Bluetooth 02AZF700 Connection Unit Indicator, 12,7mm/0,5” Type, U-WAVE fit, U-WAVE fit Bluetooth 02AZD790A U-WAVE-T Connection Cable A, with Data Button IP Caliper Type 02AZD790B U-WAVE-T Connection Cable B, with Data Button IP Micrometer Type 02AZD790C U-WAVE-T Connection Cable C, Straight, with Data Button 02AZD790D U-WAVE-T Connection Cable D, Flat 10Pin Type 02AZD790E U-WAVE-T Connection Cable E, Round 6Pin Type 02AZD790F U-WAVE-T Connection Cable F, Flat Straight Type 02AZD790G U-WAVE-T Connection Cable G, Flat Straight IP Type 02AZG011 U-WAVE-T Connection Cable SF, for Digimatic S1 Interface 63BAA057 U-WAVE T External Power Supply Adapter 02AZF670 U-WAVE fit Transmitter Mounting Plate, for ID-C, ID-S and ID-F Digital Indicator 02AZF675 U-WAVE fit Transmitter Mounting Plate, for ID-N Digital Indicator 02AZE200 U-WAVE Transmitter Mounting Plate, Universal Type 02AZE990 U-WAVE Transmitter Mounting Plate, for QM-Height 12AAY486 U-WAVE-T Transmitter Mounting Plate, for LH-600F/FG All products to be sold to commercial customers. Product illustrations are without obligation. Product descriptions, 24 All products to be sold to commercial customers. Product illustrations are without obligation. Product descriptions, in particular any and all technical specifications, are only binding when explicitly agreed upon.
U-WAVE 264-620 + 02AZF310 U-WAVE-TC (Transmitter) + Connection Unit 264-622 + 02AZF310 U-WAVE-TM (Transmitter) + Connection Unit 02AZD730G + 02AZD790A U-WAVE-T (Transmitter) + Connection Cable 02AZF670 + U-WAVE-TM + 02AZD790F 02AZE200 + U-WAVE-T + 02AZD790F U-WAVE (Transmitter) No. Measuring Instruments Remarks Data reception indication Transmission output Type Mass [g] 264-620 100, 150, 200, 300 mm IP67 caliper/standard caliper IP67 LED (green, red, orange) 2,5 mW (4 dBm) or below U-WAVE-TC (U-WAVE fit) 20 264-621 100, 150, 200, 300 mm IP67 caliper/standard caliper Standard Buzzer and LED (green, red, orange) 2,5 mW (4 dBm) or below U-WAVE-TC (U-WAVE fit) 20 264-622 COOLANT PROOF (IP65) micrometer, indicator IP67 LED (green, red, orange) 2,5 mW (4 dBm) or below U-WAVE-TM (U-WAVE fit) 20 264-623 COOLANT PROOF (IP65) micrometer, indicator Standard Buzzer and LED (green, red, orange) 2,5 mW (4 dBm) or below U-WAVE-TM (U-WAVE fit) 20 02AZD730G Indicator, 3-Point Inside Micrometer, Carbon Fibre Caliper, Height Gauge, a.s.o IP67 LED (green, red, orange) 2,5 mW (4 dBm) or below U-WAVE-T for miscellaneous instruments 23 02AZD880G Indicator, 3-Point Inside Micrometer, Carbon Fibre Caliper, Height Gauge, a.s.o Standard Buzzer and LED (green, red, orange) 2,5 mW (4 dBm) or below U-WAVE-T for miscellaneous instruments 23 U-WAVE-R (Receiver) for all Mitutoyo U-WAVE Transmitter (except U-WAVE Bluetooth) No. Remarks Number of U-WAVE-R units that can be connected to PC Number of U-Wave-T units that can be connected Transmission output Type Mass [g] 02AZD810D U-WAVE-R + Software (U-WAVEPAK) Up to 16 Up to 100 1 mW (0 dBm) or below U-WAVE-R 130 02AZD810D U-WAVE-R (Receiver) Transmitter and Connection Unit (see page after next page) for Caliper (U-WAVE-TC + 02AZF300) Transmitter and Connection Unit (see page after next page) for Micrometer (U-WAVE-TM + 02AZF310) Transmitter and Connection Cables (see page after next page) e.g. for Digital Indicator All products to be sold to commercial customers. Product illustrations are without obligation. Product descriptions, in particular any and all technical specifications, are only binding when explicitly agreed upon. 25
